Analog Devices Inc. ADRF5549-EVALZ Evaluation Board
Analog Devices Inc. ADRF5549-EVALZ Evaluation Board is designed to evaluate ADRF5549 Dual-Channel RF Front-End Modules (FEMs). This evaluation board features an easy connection to test the equipment and a through-line for calibration. The ADRF5549-EVALZ board operates at a frequency range of 1.8GHz to 2.8GHz and at a supply voltage of 5V.
Features
- Evaluate ADRF5549 Dual-Channel RF FEMs
- Easy connection to test equipment
- Through-line for calibration
Related Dual Channel RF FEM
Analog Devices Inc. ADRF5549 Dual-Channel RF FEMs
Designed for Time Division Duplexing (TDD) applications that operate from 1.8GHz to 2.8GHz.
Additional Resource
Schematic
